    Product Details:

    Place of Origin: china
    Brand Name: zealchon
    Certification: iso
    Model Number: a79

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: $10000
    Packaging Details: wooden box
    Delivery Time: 7days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 100 sets/month
    Contact Now
    Detailed Product Description
    Displacement Detection Range: 0 ~ 30mm Deformation Detection Resolution: 0.001mm
    Deformation Detection Accuracy: ± 0.005mm Cylinder Pressure Range: 0.5 MPa ~ 1.4MPa

    A79 Large Roller Compactor Pneumatic Tyred Roller,Asphalt Mixture rutting tester,Bitumen Wheel Rutting Tester



    This product measured asphalt mixture high temperatures rutting resistance, calculation of asphalt mixture dynamic stability.That is at specified temperature and load conditions, the deformation rate rubber wheel ruts formed by walking back and forth, the number of walking every 1mm deformation generates representation, can also be used for testing high temperature stability of asphalt mixture at the construction site test. Can test two specimen for rutting test at the same time,Convenient user-friendly design: Auto rise or put down trials rubber tire.



    According to People's Republic of China Ministry of Transportation Industry Standards "JTG E20-2011 Asphalt and Bituminous Mixtures Testing Procedures For T0719-2011 Asphalt Mixture Rutting Test" regulation.

    -indent:18.0pt;mso-char-indent-count:1.5'>This product measured asphalt mixture high temperatures rutting resistance, calculation of asphalt mixture dynamic stability.That is at specified temperature and load conditions, the deformation rate rubber wheel ruts formed by walking back and forth, the number of walking every 1mm deformation generates representation, can also be used for testing high temperature stability of asphalt mixture at the construction site test. Can test two specimen for rutting test at the same time,Convenient user-friendly design: Auto rise or put down trials rubber tire.



    Technical parameters
    parameters name Details
    Test Mold Size 300mm * 300mm * 50mm
    300mm * 300mm * 60mm
    300mm * 300mm * 80mm
    300mm * 300mm * 100mm
    Temperature control range 30 ℃ ~ 80 ℃
    Temperature detection resolution 0.1 ℃
    Temperature control accuracy ± 0.5 ℃
    Thermostatic chamber Trials temperature 60 ℃ ± 1 ℃
    Displacement detection range 0 ~ 30mm
    deformation detection resolution 0.001mm
    deformation detection accuracy ± 0.005mm
    Rubber wheels on test pieces pressure the factory tune set to 0.7MPa
    cylinder pressure range 0.5 MPa ~ 1.4MPa
    Rubber Wheel Size Diameter 200mm Wheel Width 50mm thickness 15mm rubber wheel
    Trials wheel walking distance 230mm
    Round rolling speed 42 beats / min
    Power; Rated power 380V AC, 3.5kW; 220VAC, 500W
    Body dimensions length × width × height: 2100mm × 1000mm × 1650mm
    Main Body Net Weight 860 kg
    Application Software For Environmental Windows 2000/Windows XP
    According to customer needs, can simulate primary, secondary, surface rutting Trials, the pressure can be adjusted according to need set





    Specification
    item
    value
    Warranty
    1 year
    Certification
    ISO
    Customized support
    OEM
    Place of Origin
    China

    Shaanxi
    Brand Name
    Zealchon
    Model Number
    a079
    Power
    Electronic
    Temperature control range
    30 ℃ ~ 80 ℃
    Thermostatic chamber Trials temperature
    60 ℃ ± 1 ℃
    Displacement detection range
    0 ~ 30mm
    deformation detection resolution
    0.001mm
    Warranty
    1 Year
    Power supply
    220V 50Hz
    Sample size
    280 x 340 mm 300 x 300 mm
    Sample height
    40-100 mm
    Test load
    up to 705 N
    Measuring range of wheel track
    0-20 mm , 0.1 mm accuracy
    Test modes
    Wet, Wet heat, Dry and Dry heat computer controlled for fully automatic operation including display of test result on computer
    screen
    Packing & Delivery
    A79 Large Roller Compactor Pneumatic Tyred Roller,Asphalt Mixture rutting tester,Bitumen Wheel Rutting Tester (Research-
    A79 Large Roller Compactor Pneumatic Tyred Roller,Asphalt Mixture rutting tester,Bitumen Wheel Rutting Tester (Research-
    wooden box
    Company Profile
    A79 Large Roller Compactor Pneumatic Tyred Roller,Asphalt Mixture rutting tester,Bitumen Wheel Rutting Tester (Research-
    A79 Large Roller Compactor Pneumatic Tyred Roller,Asphalt Mixture rutting tester,Bitumen Wheel Rutting Tester (Research-
    A79 Large Roller Compactor Pneumatic Tyred Roller,Asphalt Mixture rutting tester,Bitumen Wheel Rutting Tester (Research-
    Xi 'an Zealchon electronic technology co., LTD, located in new technology industry development zone in Xi'an, an ancient city in China. It covers an area of 7500 square meters of building area. Zealchen specialize in civil engineering research and experimental apparatus; another is the semiconductor laser research and development.On one hand, currently based on civil experimental instrument research, the research team is founded by the personnel who come from Chang 'an university, Xi 'an polytechnic university, Xi 'an petroleum university, which has the top technology in this expertise. In addition, its research and development has accomplished a series of leading domestic and international standards, first-class technology of asphalt and asphalt mixture, road, bridge deck, geotechnical, structural testing instruments, even more, some of the products fill the blank of similar equipment at home and abroad, won national, ministerial, provincial awards.
