Name: A78 Hydraulic Specimen Wheel-Track Molding Machine (Roller Compactor)
Brand: Xian Zealchon Electronic Technology Co., Ltd.
SKU: A78
Price: 6500 USD
Availability: InStock

Home Products asphalt testing machine

A78 Hydraulic Specimen Wheel-Track Molding Machine (Roller Compactor)

Product Details:

Place of Origin:	China
Brand Name:	zealchon
Certification:	ISO
Model Number:	A78

Payment & Shipping Terms:

Minimum Order Quantity:	1set
Price:	$6500
Packaging Details:	wooden box
Delivery Time:	7days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	100sets/month

Contact Now

Detailed Product Description

Test Mold Size:	300mm * 300mm *50mm	Roller Compacted Length:	300mm
Roller Compacted Speed:	17 Per Minute Round Trip	Temperature Control Range:	50 ~ 200 ℃ (factory Setting Is: 100 ℃)
Temperature Control Accuracy:	± 5 ℃. Oil Heating

Product Description

Specification

A78 Hydraulic specimen Wheel-Track Molding Machine (Roller Compactor)
This product is suitable for the production of physical mechanics in the laboratory method using wheels grind Asphalt Mixture test pieces, measuring Asphalt Mixture temperature rutting resistance, asphalt mix design properties such as high temperature stability Trials. Meet the People's Republic of China Ministry of Transportation industry standard "JTG E20-2011 asphalt and asphalt testing procedures, T0703-2011 Asphalt Mixture test pieces production methods (round grind Act)."

The product consists of a temperature control module, pressure control module, the number of Roller Compacted control module, hydraulic, servo cylinders, Roller Compacted wheels, the standard test mold and so on. You can set the temperature of Roller Compacted wheel, Roller Compacted and compacting the number of line loads.

halt Mixture test pieces, measuring Asphalt Mixture temperature rutting resistance, asphalt mix design properties such as high temperature stability Trials. Meet the People's Republic of China Ministry of Transportation industry standard "JTG E20-2011 asphalt and asphalt testing procedures, T0703-2011 Asphalt Mixture test pieces production methods (round grind Act)."

item	value
Certification	ISO
Customized support	OEM
Place of Origin	China
	Shaanxi
Brand Name	Zealchon
Model Number	A078
Power	Electronic
Test mold Size	300mm * 300mm *50mm
Compaction line loads control range	200 ~ 400 N
Roller Compacted Length	300mm
Roller Compacted times	from 0 to 9999 times
Roller Compacted speed	17 per minute round trip
Temperature control range	50 ~ 200 ℃ (factory setting is: 100 ℃)
Temperature control accuracy	± 5 ℃. Oil heating
Rated power	3.5kW 380V AC

Packing & Delivery

a. Inner package: dust-proof plastic bag b. Outer package: standard export wooden case with pallet c. Special package: according to buyer's requirements d. The packages suitable for international transport by sea, by air or by any other delivery methods

Company Profile

Xi 'an Zealchon electronic technology co., LTD, located in new technology industry development zone in Xi'an, an ancient city in China. It covers an area of 7500 square meters of building area. Zealchen specialize in civil engineering research and experimental apparatus; another is the semiconductor laser research and development.On one hand, currently based on civil experimental instrument research, the research team is founded by the personnel who come from Chang 'an university, Xi 'an polytechnic university, Xi 'an petroleum university, which has the top technology in this expertise. In addition, its research and development has accomplished a series of leading domestic and international standards, first-class technology of asphalt and asphalt mixture, road, bridge deck, geotechnical, structural testing instruments, even more, some of the products fill the blank of similar equipment at home and abroad, won national, ministerial, provincial awards.

Our technical support team, marketing, and web development teams make their homes in china as well, and are dedicated to providing comprehensive customer support and services.

FAQ

1. who are we?

We are based in Shaanxi, China, start from 2014,sell to Eastern Asia(30.00%),South Asia(30.00%),Mid East(15.00%),Western Europe(15.00%),Southern Europe(10.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?

Always a pre-production sample before mass production;

Always final Inspection before shipment;

3.what can you buy from us?

Bitumen Testing,Material Testing,Aggregate Testing Machine,Soil Testing,Laboratory machine

4. why should you buy from us not from other suppliers?

We have 20 years of experience in design research and development, with the guidance of professors and researchers from the Well-known institutions in China,developed a series of leading domestic detecting instrument and laser products.

5. what services can we provide?

Accepted Delivery Terms: FOB,CIF；

Accepted Payment Currency:USD,EUR,JPY,CAD,AUD;

Accepted Payment Type: T/T,Credit Card,Western Union,Escrow;

Language Spoken:English,Chinese,Spanish,Japanese
