ZCQ45 vibro-replacement stone columns has a vibrator

Home Products stone columns Vibroflot Equipment

ZCQ45 vibro-replacement stone columns has a vibrator

Product Details:

Place of Origin:	China
Brand Name:	zealchon
Certification:	ISO
Model Number:	ZCQ45

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	$15000
Packaging Details:	wooden box
Delivery Time:	7days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	100 sets/month

Contact Now

Detailed Product Description

Rotational Speed:	1450	Nominal Current:	80
Frequency:	24	Brake Torque:	47

Vibroflotation mechanical

Name:Vibroflotation mechanical Product Code:zcq Model:zcq30,zcq45,zcq55,zcq75,zcq100,zcq130,zcq150,zcq180 Updated: Products Unit:Xi’an Vibroflotation mechanical Co., Ltd. Views:512 More Images:

Name:Vibroflotation mechanical
Product Code:zcq
Model:zcq30,zcq45,zcq55,zcq75,zcq100,zcq130,zcq150,zcq180
Updated:
Products Unit:Xi’an Vibroflotation mechanical Co., Ltd.
Views:512
More Images:

Details

Model Data			ZCQ 45	ZCQ 55	ZCQ 75	ZCQ 100	ZCQ 130	ZCQ 150	ZCQ 180
Electrical machinery	Nominal capacity	kw	45	55	75	100	130	150	180
	Rotational speed	r/mim	1450	1450	1450	1450	1450	1450	1450
	Nominal current	A	80	100	150	190	250	290	350
Vibrated mechanism	frequency	HZ	24	24	24	24	24	24	24
	Brake torque	N.m	47	56	69	78	88	96	106
	Rated force	kN	110	130	160	180	200	225	250
	Amplitude when empty	mm	≥10	≥9.8	≥9.5	≥9.2	≥9.0	≥8.8	≥8.5
	Current when empty	A	≤35	≤40	≤50	≤60	≤70	≤80	≤90
diameter		mm	360	390	426	426	426	426	426
length		mm	≤2230	≤2465	≤2600	≤2750	≤2860	≤3000	≤3150
Gross weight		kg	1000	1350	1800	1950	2200	2350	2600

ZCQ130 Vibroflotation mechanical stone columns
