C107 Rock fracture toughness tester for rock lab testing machine

$C107 Rock fracture toughness tester for rock lab testing machine$

Product Details:

Place of Origin:	China
Brand Name:	zealchon
Certification:	ISO
Model Number:	c107

Payment & Shipping Terms:

Minimum Order Quantity:	1set
Price:	$6800-10000
Packaging Details:	wooden box
Delivery Time:	7days
Payment Terms:	L/C, Western Union, T/T
Supply Ability:	100sets/month

Contact Now

Detailed Product Description

Maximum Load:	200kN±5N	Sample Size:	Diameter 48mm~54mm, Length Is Greater Than 3.5~4 Times Of Diameter Ratio.
Loading Rate:	: 3N~5KN/s	. Loading Speed:	0.001~10mm/min
Displacement Rate:	6×10-4mm/s.	Stroke Range:	: 0~10mm±0.001mm

Product Description

$C107 Rock fracture toughness tester for rock lab testing machine$

C107 Rock fracture toughness tester for rock lab testing machine

Application:

This instrument measures the fracture toughness (flexural strength) of rock materials. Fracture toughness is mainly used to classify and characterize intact rock from the perspective of crack propagation resistance. It can also be used as an indicator of rock fragmentation process (crushing tunnel excavation) and for analysis of hydraulic fracture and stability.

Technical parameter

1. The three-point bending method of cylindrical specimens with straight incisions is used to determine the fracture toughness of rocks, which is suitable for hard rocks.
2. Sample size: diameter 48mm~54mm, length is greater than 3.5~4 times of diameter ratio.
3. The ratio of the distance between the two supporting points to the diameter is 3.33.
4. The ratio of the depth of the straight incision to the diameter is 0.35~0.50 The width of the incision is not more than 1.5mm
5. Maximum load: 200kN±5N
6. Three fulcrum bending test fixture: the center position of the upper fulcrum; the distance between the lower fulcrums is 200mm (applicable to 50×50×200mm)
7. Loading rate: 3N~5KN/s
8. Loading speed: 0.001~10mm/min
9. Displacement rate: 6×10-4mm/s.
10. Stroke range: 0~10mm±0.001mm
11. Clip-on extensometer: gauge length 3.0 mm; measuring range +2.5 mm/-1.0 mm (optional)
12. Real-time LCD display and vertical load. Standard industrial computer software is used to process the acquisition force, deformation crack, expansion deformation, original data, graphic curve-deformation curve, and rock crack propagation deformation curve.
PC software
