YES-D Series Digital Display concrete cube press machine
1. Application
Digital display compression testing machine mainly used for concrete and other material compression resist testing. Widely used in metallurgy, building materials, space flight and aviation, colleges and universities, R&D institution lines. The test operation and data processing meets standard requirements.
2. Main Specifications
| Model |
YES-3000D |
| Max. load |
3000kN/300Ton |
| Machine Class |
1 class |
| Range of test force |
4% ~100%FS |
| Testing space adjust method |
Electric adjust |
| Indicating value accuracy |
±1% |
| Piston stroke |
80mm |
| Distance between platens |
320mm |
| Upper platen size |
265×265 mm
(Can be customized)
|
| Lower platen size |
360×285
(Can be customized)
|
| Display |
LCD |
| Power supply |
AC380V/50Hz/3 phase(can be customized) |
| Size |
1000×500×1500 |
| Weight |
1500kg |
3. Main configuration:
| Main unit and oil source control cabinet |
1 set |
| High precision compression sensor |
1 pc |
| English version operate instrument |
1 suit |
| Micro printers |
1 set |
| Specialized compression attachment |
1 suit |
| Accompany tools |
1 suit |
| Accompany documents |
1suit |
| Bending fixture |
Optional |
Service:
1. Warranty 1 year of replacement and return.
2, Providing factory visit and study, technical training
3, 24-hour technical support by e-mail or phone
4, Providing laboratory construction program design guidelines
5, Providing product design and OEM service
