C126 Tripod for standard penetration test equipment for soil testing machine
Application:
It is used to determine allowable load capacity of all kinds of soil. It can also find out uniformity coefficient of horizontal and vertical direction and identify the position of the pile foundation bearing layer and estimate the
bearing capacity of single pile. Electric penetrometer solve disadvantages like slow, tire, Much of choose and employ persons In the manual operation.
Please notice that:
This machine can only pull out one meter at a time of use, if under any circumstances rods in ground exceeded
2 meters,then you will need an external crane, excavator or any other heavy machines to pull the rods out"
Specification:
| parameters |
details |
| hammer quality |
63.3kg |
| drop distance |
760mm |
| Speed |
15 strike/minute, Plus or minus 2 / min |
| Dimension |
L1.3m*W2.1m*H2.1m |
| feeler lever outside diameter |
42mm |
| CHEESE taper 60°, The cone diameter 74mm |
Service:
1. Warranty 1 year of replacement and return.
2, Providing factory visit and study, technical training
3, 24-hour technical support by e-mail or phone
4, Providing laboratory construction program design guidelines
5, Providing product design and OEM service
