DYE-300 Digital concrete flexural machine

DYE-300 Digital concrete flexural machine

DYE-300 Digital concrete flexural machine

Product Details:

Place of Origin: China
Brand Name: zealchon
Certification: iso
Model Number: DYE-300

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: $2500
Packaging Details: wooden box
Delivery Time: 7days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100sets/month
Contact Now
Detailed Product Description
The Maximum Load: 300KN The Minimum Resolution: 0.01KN
Anti-roll Diameter:: φ30mm The Center Distance Between The Folding Roller: φ165mm
The Center Of The Anti-roll Between The Distance: 450mm (adjustable)

Product Description

DYE-300 Digital concrete flexural machine



DYE-300 Digital concrete flexural machine





Specification:



1, The maximum load: 300KN
2, Show the relative error: ± 1%
3, The minimum resolution: 0.01KN
4, The maximum pressure of oil: 25Mpa
5, Anti-roll diameter: φ30mm
6, The center distance between the folding roller φ165mm
7, On the center of the anti-roll between the 150mm
8, The center of the anti-roll between the distance 450mm (adjustable)
9, The pressure plate diameter: φ160mm
10, Between the upper and lower platen clearance: 180mm
11, The piston diameter × maximum stroke: φ125 × 100mm
12, The motor power: 0.75KW
13, Dimensions: 840 × 530 × 1450mm
14, Net weight: 550kg





Product pictures:









Lab Display



Trade Shows





After-Sales Service



Packing and Shipping







Certifications





Contact Us









Service:





1. Warranty 1 year of replacement and return.



1, Providing factory visit and study, technical training



2, 24-hour technical support by e-mail or phone



3, Providing laboratory construction program design guidelines



4, Providing product design and OEM service
