Place of Origin: | china |
Brand Name: | zealchon |
Certification: | iso |
Model Number: | zcq130 |
Minimum Order Quantity: | 1 set |
---|---|
Price: | $20000 |
Packaging Details: | wooden box |
Delivery Time: | 7days |
Payment Terms: | L/C, T/T, Western Union, MoneyGram |
Supply Ability: | 10 sets/ month |
Rated Power: | 130 | Rotating Spee: | 1450 (1950) |
---|---|---|---|
Current Rating: | 256 | Vibration Frequenc: | 24 |
Moment: | 88 | Exciting Force: | 210-380 |
Model Data |
ZCQ 45 |
ZCQ 55 |
ZCQ 75 |
ZCQ 100 |
ZCQ 130 |
ZCQ 150 |
ZCQ 180 |
||
Electrical machinery |
Nominal capacity | kw | 45 | 55 | 75 | 100 | 130 | 150 | 180 |
Rotational speed | r/mim | 1450 | 1450 | 1450 | 1450 | 1450 | 1450 | 1450 | |
Nominal current | A | 80 | 100 | 150 | 190 | 250 | 290 | 350 | |
Vibrated mechanism | frequency | HZ | 24 | 24 | 24 | 24 | 24 | 24 | 24 |
Brake torque | N.m | 47 | 56 | 69 | 78 | 88 | 96 | 106 | |
Rated force | kN | 110 | 130 | 160 | 180 | 200 | 225 | 250 | |
Amplitude when empty | mm | ≥10 | ≥9.8 | ≥9.5 | ≥9.2 | ≥9.0 | ≥8.8 | ≥8.5 | |
Current when empty | A | ≤35 | ≤40 | ≤50 | ≤60 | ≤70 | ≤80 | ≤90 | |
diameter | mm | 360 | 390 | 426 | 426 | 426 | 426 | 426 | |
length | mm | ≤2230 | ≤2465 | ≤2600 | ≤2750 | ≤2860 | ≤3000 | ≤3150 | |
Gross weight | kg | 1000 | 1350 | 1800 | 1950 | 2200 | 2350 | 2600 |
