ZCQ100 Vibro-replacement stone columns vibrator

ZCQ100 Vibro-replacement stone columns vibrator

    • ZCQ100 Vibro-replacement stone columns vibrator
    • ZCQ100 Vibro-replacement stone columns vibrator
    • ZCQ100 Vibro-replacement stone columns vibrator
    • ZCQ100 Vibro-replacement stone columns vibrator
    • ZCQ100 Vibro-replacement stone columns vibrator
  • ZCQ100 Vibro-replacement stone columns vibrator

    Product Details:

    Place of Origin: china
    Brand Name: zealchon
    Certification: iso, ce
    Model Number: zcq100

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: $18000
    Packaging Details: wooden box
    Delivery Time: 7days
    Payment Terms: L/C, T/T, Western Union, Western Union, MoneyGram, D/A, D/P
    Supply Ability: 10 sets/ month
    Contact Now
    Detailed Product Description
    Rated Power: 100 Rotating Speed: 1450 (1950)
    Current Rating: 196 Vibration Frequency: 24
    Moment: 78 Exciting Force: 190-350
    Empty Vibration Amplitude: ≥15

    Product type


    Now the main production:



    30KW type vibrator,

    45KW type vibrator,

    55KW type vibrator,

    75KW type vibrator,

    100KW type vibrator,

    130KW type vibrator,

    150KW type vibrator,

    180KW type Vibro device.



    ZCQ100 Vibro-replacement stone columns vibrator





    ZCQ series variable frequency electric drive Vibroflot technical parameters



    specification ZCQ45 ZCQ55 ZCQ75 ZCQ100 ZCQ130 ZCQ150 ZCQ180 ZCQ240 ZCQ300
    Vibro
    Motor
    rated power kw 45 55 75 100 130 150 180 240 300
    Rotating speed r/mim 1450 (1950) 1450 (1950) 1450 (1950) 1450 (1950) 1450 (1950) 1450 (1950) 1450 (1950) 1450 (1950) 1450 (1950)
    Current Rating A 86 110 150 196 256 291 350 475 590
    Vibration
    move
    machine
    body
    Vibration frequency HZ 24 24 24 24 24 24 24 24 24
    Moment N.m 47 56 69 78 88 96 106
    Exciting force kN 110-200 130-235 180-325 190-350 210-380 230-429 280-506 325-588 380-687
    Empty vibration amplitude mm ≥18 ≥16 ≥15 ≥15 ≥16 ≥18 ≥21 ≥23 ≥26
    Empty LO current A ≤35 ≤40 ≤50 ≤60 ≤70 ≤80 ≤90 ≤120 ≤150
    The outer diameter of the body mm 351 377 426 426 426 426 426 480 480
    Body length mm ≤2230 ≤2465 ≤2600 ≤2750 ≤2860 ≤3000 ≤3150 ≤3100 ≤3200
    The total mass kg 1000 1350 1800 1950 2200 2300 2400 2550 2660







    Factory introduction:



    we are located in the historic city of China - the ancient capital of Xi'an Chanba New Area, location and convenient transportation, adjacent to China's largest inland port - Xi'an International Port District and a number of Expressway, exit from the motorway just a few hundred meters. Established in 1987, is set research and development, production, sales, promotion as one of the weak foundation and construction machinery are widely used trenchless technology engineering company. Enterprises always adhere to the quality first, the credibility of the first, with technical superiority, strong professional strength and excellence and pioneering spirit of forging ahead in Vibroflot development, production and sales, always in the same industry-leading level.
    Enterprise since its inception, with its own tenacious struggle, flexible and efficient management system and a high level of technical research and development, from weak to strong, continue to occupy the domestic market and exported to overseas, sales rose, after twenty years of effort, It has become a domestic and international Vibroflot production and construction technology leader.



    ZCQ100 Vibro-replacement stone columns vibrator
