Platinum / Silver / Gold purity Tester Energy Dispersive X-ray Fluorescence

Product Details:

Place of Origin:	China
Brand Name:	zealchon
Certification:	iso CE
Model Number:	EXF9600

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	$13000
Packaging Details:	Wooden box
Delivery Time:	Within 7days
Payment Terms:	T/T
Supply Ability:	100 sets

Contact Now

Detailed Product Description

Power:	Electronic	Usage:	Gold Testing Machine
Working Principle:	Energy Dispersive X-ray Fluorescence	Size(mm)::	450400350
Testable Elements::	Detects 20+ Elements Precisely Better Than Fire Assay. Identifies Prohibited Elements (Powder) Iridium, Ruthenium, Osmium, Etc	Detector::	Si-Pin

Product Description

9600 2021 High Technology XRF Gold testing machine for pawn shops and jewelry with high accuracy

9600 is the latest XRF gold analyzer with high stability and faster processing HDSP technology(Hybrid Digital Signal Processor). Our New Generation tech is improved for better stability and accuracy for wide range of Au(Gold) samples and also Ag Pt based Jewellery samples. Specially designed Integrated Industrial grade PC and Chipset ensures very high data transmission between the DSP and Processor for reducing the Data loss and Transmission time.

Results are more stable and accurate and better than fire assay standard to detect Prohibited elements like - Ir, Ru, Re, Os, etc.

9600 occupies 30% lesser space than the current range of gold tester. Also its special electronic lock forbids user from

intervening the testing process. Large testing chamber guarantees testing of almost all types of Jewellery without any compromise.Cloud technology enable system provides Centralized data and Instrument monitoring for Businesses with Multiple branches and when instruments are spread in various locations.

Print results along with sample value estimation with integration of Electronic weighing balance and based on Current Gold prices(configurable as per customer request)

Product Paramenters

Working Principle	Energy Dispersive X-ray Fluorescence
Size(mm):	450400350
Precision:	±0.05%
Operating Environment:	Temperature -11~46℃ Humidity ≤70%
High Voltage:	0~50KV/0~1MA
Detector:	Si-Pin
Resolution:	145Kev±5
Testable Elements:	Detects 20+ Elements Precisely better than Fire Assay. Identifies Prohibited Elements (Powder) Iridium, Ruthenium, Osmium, etc
N/G Weight(KG):	33
