DYLB type CPT Drill rig vehicle for soil cpt testing machine Crawler Type CPTU soil Static Cone Penetrometers (CPT)

DYLB type CPT Drill rig vehicle for soil cpt testing machine Crawler Type CPTU soil Static Cone Penetrometers (CPT)

    • DYLB type CPT Drill rig vehicle for soil cpt testing machine Crawler Type CPTU soil Static Cone Penetrometers (CPT)
    • DYLB type CPT Drill rig vehicle for soil cpt testing machine Crawler Type CPTU soil Static Cone Penetrometers (CPT)
    • DYLB type CPT Drill rig vehicle for soil cpt testing machine Crawler Type CPTU soil Static Cone Penetrometers (CPT)
    • DYLB type CPT Drill rig vehicle for soil cpt testing machine Crawler Type CPTU soil Static Cone Penetrometers (CPT)
    • DYLB type CPT Drill rig vehicle for soil cpt testing machine Crawler Type CPTU soil Static Cone Penetrometers (CPT)
    • DYLB type CPT Drill rig vehicle for soil cpt testing machine Crawler Type CPTU soil Static Cone Penetrometers (CPT)
  • DYLB type CPT Drill rig vehicle for soil cpt testing machine Crawler Type CPTU soil Static Cone Penetrometers (CPT)

    Product Details:

    Place of Origin: China
    Brand Name: zealchon
    Certification: ISO CE
    Model Number: DYLB

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: $25000
    Packaging Details: wooden box
    Delivery Time: 7days
    Payment Terms: L/C, D/A, D/P, T/T, Western Union
    Supply Ability: 100 sets/ month
    Contact Now
    Detailed Product Description
    Static Test The Pull Force:: 230 KN Static Agents Rated Penetration Force: 200 KN
    Engine Power:: 21 ~ 32 Kw Speed: 2000 ~ 2600 (r/min)
    Walking Speed: 1 ~ 4 (km/h)

    Product Description

    Crawler Type CPTU soil Static Cone Penetrometers (CPT)


    Features:

    Crawler Type CPTU soil Static Cone Penetrometers (CPT) is used hydraulic excavators and crawler chassis bracing, it can walk in the beach, flood, sand, paddy and other harsh environment to carry out CPT job, icy roads can still walk.

    It has applied the advanced hydraulic technology, using a combination of sub-chip multi-valve, compact structure, small size, easy installation, low pressure loss, overload characteristics of a good relief.
    The CPT car can a machine is not only ideal for static cone penetration test, configure attachment may extend for CPTU (CPTU), since drilling pressuremeter (PMT), flat dilatometer, Vane (VCT), pressure-velocity (WVT) and other in-situ test trials.

    The biggest advantage: fuel-efficient, saving manpower, high performance, high efficiency Under the country's first fully hydraulic rotary anchoring device (patent number: 201220081488.1 and patent number: 201220081492.8 configuration core barrel and drill Opening hardened concrete pavement etc.) and self-loading and unloading trucks devices (patent number: 201220382939.5), efficient and durable structure Compact, convenient and quick.

    It only needs small power diesel engines for the whole vehicle power system, on a large extent, it reduced the fuel consumption and maintenance costs.

    The operator can boot side edge flapper, safe and save manpower, at least two individuals can be a normal operation, it can greatly improve the work efficiency.

    Parameter
    Engine
    single cylinder 180 diesel engine horizontal four stroke water cooling
    Rated power - speed
    5.67KW-2600r / min
    CPT hydraulic cylinder device
    rated penetration force 200KN
    Rated pull force
    240KN
    Stroke
    570mm
    Weight
    180 kg
    Ground anchor form
    single leaf or multi-leaf anchor anchor
    Maximum working environment Permissible temperature:
    45 ° C
    Supporting probe
    10cm2
    Measuring instruments
    static data collection or automatic collection of European and American brands
    Testing results
    DYLB type CPT Drill rig vehicle for soil cpt testing machine Crawler Type CPTU soil Static Cone Penetrometers (CPT)
    DYLB type CPT Drill rig vehicle for soil cpt testing machine Crawler Type CPTU soil Static Cone Penetrometers (CPT)
    DYLB type CPT Drill rig vehicle for soil cpt testing machine Crawler Type CPTU soil Static Cone Penetrometers (CPT)
    Details Images
    DYLB type CPT Drill rig vehicle for soil cpt testing machine Crawler Type CPTU soil Static Cone Penetrometers (CPT)
    DYLB type CPT Drill rig vehicle for soil cpt testing machine Crawler Type CPTU soil Static Cone Penetrometers (CPT)
    Related products
    DYLB type CPT Drill rig vehicle for soil cpt testing machine Crawler Type CPTU soil Static Cone Penetrometers (CPT)
    Company Profile
    DYLB type CPT Drill rig vehicle for soil cpt testing machine Crawler Type CPTU soil Static Cone Penetrometers (CPT)
    DYLB type CPT Drill rig vehicle for soil cpt testing machine Crawler Type CPTU soil Static Cone Penetrometers (CPT)
    DYLB type CPT Drill rig vehicle for soil cpt testing machine Crawler Type CPTU soil Static Cone Penetrometers (CPT)
    DYLB type CPT Drill rig vehicle for soil cpt testing machine Crawler Type CPTU soil Static Cone Penetrometers (CPT)
    DYLB type CPT Drill rig vehicle for soil cpt testing machine Crawler Type CPTU soil Static Cone Penetrometers (CPT)
    DYLB type CPT Drill rig vehicle for soil cpt testing machine Crawler Type CPTU soil Static Cone Penetrometers (CPT)
    DYLB type CPT Drill rig vehicle for soil cpt testing machine Crawler Type CPTU soil Static Cone Penetrometers (CPT)
    After-service
    DYLB type CPT Drill rig vehicle for soil cpt testing machine Crawler Type CPTU soil Static Cone Penetrometers (CPT)
    FAQ
    1. Who are we?
    We are based in Shaanxi, China, start from 2014, sell to Eastern Asia(30.00%), South Asia(30.00%), Mid East(15.00%), Western Europe(15.00%), Southern Europe(10.00%). There are total about 11-50 people in our office.

    2.What can you buy from us?
    Bitumen Testing, Material Testing, Aggregate Testing Machine, Soil Testing, Laboratory machine.

    3.How can we guarantee quality?
    Always a pre-production sample before mass production; Inspection and Calibration: technician do it strictly before shipment.

    4. Why should you buy from us not from other suppliers?
    We have 20 years of experience in design research and development, with the guidance of professors and researchers from the Well-known institutions in China,developed a series of leading domestic detecting instrument and laser products.with a dedicated after-sales team. Support product customization.

    5. What services can we provide?
    Accepted Delivery Terms: FOB, CIF, EXW, DDP, Express Delivery;
    Accepted Payment Currency: USD, EUR, JPY, CAD, AUD;
    Accepted Payment Type: T/T, Credit Card, PayPal, Western Union or other payment can be negotiated before shipment.
    Language Spoken:English,Chinese,Spanish,Japanese
    Training: usually do it in our factory, for special requirement, can arrange technician go to customer site for training.
