Vehicular laser pavement roughness meter/Pavement Profilometer

Vehicular laser pavement roughness meter/Pavement Profilometer

Vehicular laser pavement roughness meter/Pavement Profilometer

Product Details:

Place of Origin: China
Brand Name: ZEALCHON
Certification: ISO
Model Number: B004

Payment & Shipping Terms:

Price: $15000
Packaging Details: WOODEN BOX
Delivery Time: within 12 days
Payment Terms: t/t
Supply Ability: 100 set pr month
Minimum Order Quantity: 1 set
Contact Now
Detailed Product Description
High Light:

laser surface roughness tester

,

Pavement Profilometer

,

plastic surface roughness

B004 Vehicular laser pavement roughness meter

parametersdetails
Working distance100 mm - 120 mm
Working voltage12 V with power supply and charging tools, working time: 7h-12 h
Measuring range:±20 mm Accuracy: 0.01 mm Resolution: 0.1 mm
Take distance0 mm to 20 mm ± 1 mm
Determination of minimum spacing5 m - 100 - m (can be arbitrarily set the spacing)
Test speed60 km/h

Base performance
1. Measure the measurable indicators of flatness:
The international roughness index IRI
Flatness sigma (can be reduced turbulence value)

2. The output:
Various indicators, road & pile number range, mileage,the ultra left the picture right classification number, can set a variety of data, curve, and the original data.

3. The general technical characteristics:
Detection speed: 20 km/h - 100 km/h
Continuous measurable distance: > 50 km
Minimum sampling interval: 10 mm
Sensor precision: 0.1 mm
The number of operators (including the driver) : 1-2 people
Operating temperature: 0to 50
System power supply: DC 12 V

Betweenthe bottom of the laser sensor and the clear distance pavement: 100 mm (testing)
Detection range: TRI: 0-100 m and other detection distance can be set
Test repeatability: Deviation factor: CV < 3%
