Product Description
Weight: 1.5 kg with batteries
Dimensions: 30cm(L)*23.5cm(W)*9.8cm(H)
Excitation Source: X-ray tube with Ag target; max voltage 50KV
Filters Five (5) available automatic filter positions
Detector: Peltier cooled 10 mm2 Silicon Drift Detector
Power: 2 rechargeable Li-Ion batteries; 6 hours operation per battery; AC adapter is optional
Operating Range: -10°C to 50°C
Computer/Display: with 65,536 colors; back lit; touch screen
Testing Modes Assay and Pass/Fail
Calibrations
Universal (automatically selects proper calibration); Polyethylene plastics; PVC
plastics; Mid-density (glass, ceramics); Alloys; Solders
Data Storage: 16GB standard memory.
Radiation Safety Password protected, No sample (backscatter) shutoff, five minute inactive log-in
Languages Supported: English, Chinese and other 5 languages
Warranty: One year
Standard Accessories
• Waterproof Carrying Case
• Two (2) Li-ion Batteries
• User Interface Guide
• Mini USB Cable
• 316 Stainless Steel Calibration Check Reference Coin
• Integrated Wrist Strap
• Analyzer Software
• Factory Authorized Training and Support
it is a reliable and rugged analyzer that maximizes both speed and accuracy. The need to determine whether an ID is incorrect or if longer testing is required needs to be balanced with maximum testing speed without increasing the risk of mistaken IDs or erroneous readings. X3G’ Smart Real solution automates all these decisions, enabling even inexperienced operators to maximize both speed and inspection accuracy. This powerful feature yields optimized throughput and accuracy, making the X3G an extremely productive XRF tool for alloy inspection.
